WL0840 Push Pull Linear Solenoid Presentation

What is a push pull linear solenoid that pushes and pulls?

A push-pull linear solenoid is an electromechanical device that converts electrical power into linear motion. It has a solenoid coil with a magnetic field generated by the flow of electrical current. This magnetic field moves a ferromagnetic plunger inside the solenoid coil. Depending on the design and the direction of the solenoid, the motion of the plunger either pushes or pulls an object.

Push-pull solenoids are used to accomplish a wide range of tasks, including automated systems, locks, vending machines, and medical equipment, among others. They are liked because they are quick to react, small, and work well. Push-pull solenoids are the easiest and cheapest devices to move objects along a straight line for short-stroke applications. Push-pull solenoids are the best devices to move objects along a straight line compared to motors and pneumatics, especially in applications where speed and compact size are critical, such as in robotics and automation systems.

Get A Free Quote

PDF Download

Push Pull Linear Solenoids Detailed Description

An Overview of the Push Pull Linear Solenoid Product

Push-pull linear solenoids are flexible solenoids that are designed to ensure the creation of a reliable form of linear motion. This product works in the sense that it uses electromagnetic induction to convert electrical energy into mechanical energy. When the solenoid is energized, the plunger will move to push or pull. This will turn the mechanical parts on. There are instances when this product will be used in different machines. For example, the product can be used in vending machines, smart locks, and printers, as well as different machines. This product can be used in different applications because it is small as well as fast. This product can be used to control the current in different electromechanical systems. This product can be used in a flexible as well as cost-effective manner.

WL0840 Push Pull Linear Solenoid Video

Push Pull Linear Solenoid for Electronic Devices

WL0840 Push Pull Linear Solenoid Overview

Performance Push Pull Linear Solenoid Guide

Push Pull Linear Solenoid Product Selection Tips

Durable Push Pull Linear Solenoid Design Guide

Push Pull Linear Solenoid Quality Performance

hoosing the Right Push Pull Linear Solenoid

WL0840 Push Pull Solenoid

WL0840 Push Pull Linear Solenoid datasheet

AS 0840 Dimensions- 41 x 15 x 20 mm / 1.61 x 0.59 x 0.79 inch (L*W*H);

Voltage: DC12 V or 24 V;
Frame Housing Material: Carbon Steel. It is electroplated with a zinc or nickel coating. It has passed 48 hours of salt spray testing, and it is anti-corrosion.
Plunger Material: Carbon Steel. It is electroplated with Zinc or Nickle coating. It has passed 48 hours salt spray testing, and it is anti-corrosion and compliant with RoHS .
Copper Coils: It is made with pure copper wire. Character: Good conduction and insulation, high temperature resistance.
Stroke: 4-10mm (adjustable) Material : Carbon Steel with Zinc coating
Force: 1.5-8 N (Adjustable to your requirement)
Power wattage: .24 W
Current: 1 A
Resistance: 10Ω
Lifespan: ≥200,000 times
Working Cycle: 1 s On, 9s Off

WL0840 Push Pull Linear Solenoid Application

A push-pull linear solenoid transforms electrical energy into linear motion that can be used to push or pull an object. It is used often because of its speed, small size, and dependability.

These are the most common uses of a push-pull linear solenoid:

1️⃣ Automation in Industry

This is used to make mechanical actions that occur automatically.

Some of the common uses of push-pull linear solenoids include:

Machines that automatically sort items

Tools used to pack items

Ways to lock and unlock doors

Ways to move robots

The key advantage is that it can change automatically.

2 Smart Door Locks and Access Control

Push-pull solenoids are used often in electrical locks.

Some of the uses of push-pull solenoids include:

Locks used in smart doors

Locks used in vending machines

Locks used in cabinets that contain electronics

Locks used to control access

The key advantage is that it can lock and unlock doors very fast and uses less electricity.

3 Office and Commercial Equipment

Push-pull solenoids are used to make machines that move automatically.

Some of the uses of push-pull solenoids include:

Printers

Copy machines

Machines that sell tickets

Parts used to make ATMs

Key advantage: small size that can fit small machines.

4️⃣ Systems for Cars 🚗

Used for controlling things, as well as for switching things on and off.

Some of the uses for this product are:

Lock for fuel door

Release the trunk

Gear shift lock

Systems with electronic latches

What is the main benefit of the product? How is it important for the customer?

It works well even at varying temperatures.

5️⃣ Medical Tools 🏥

Push-pull solenoids are commonly used for medical devices that require high accuracy.

Some of the uses for this product are:

Dialysis machines

Medical analyzers

Fluid control systems

Automating the lab

What is the main benefit of the product? How is it important for the customer?

It is highly accurate.

6️⃣ Vending & Self-Service Machines

Push-pull linear solenoids are commonly used for mechanical release functions.

Some of the uses for this product are

Vending machine product release

Coin control mechanisms

Ticket dispensers

Self-service kiosks

What is the main benefit of the product? How is it important for the customer?

Reliable repeated actuation.

7️⃣ Home Appliances

Push and pull solenoids are used for the automation of the movement and locking functions of coffee machines, washing machines, smart appliances, and other automatic dispensers.

What is the main benefit of the product? How is it important for the customer?

Simple structure, long service life.

✅ Summary

Push Pull Linear Solenoids are commonly used for automation, locking, medical devices, vending machines, smart appliances, etc. They are highly efficient, simple, easy to use, and highly compact.

WL0840 Push Pull Linear Solenoid Advantage and Disadvantage

Pros and Cons of Push Pull Linear Solenoid

Benefits

There are many benefits to the usage of the push-pull linear solenoids in both the mechanical and electrical systems. One of the most important things about the push-pull solenoids is that they are easy to maintain due to their simple design. These solenoids also have a fewer number of moving parts compared to the motor-driven solenoids. Because of this, they can operate for millions of cycles with little or no maintenance.

Another advantage of the solenoids is that they operate quickly. Once the solenoids are turned on, they can make things move almost instantaneously. Because of this, they can be used for tasks that need to be accomplished quickly.

Another advantage of the solenoids is that they are compact and lightweight. These solenoids can be easily integrated into small gadgets due to their compact size. These solenoids also provide a smooth motion to the mechanical parts.

Another advantage of the solenoids is that they are cheap to make. Because of this, they can be used to make many things.

Cons

Although the push-pull solenoids have a few benefits, they also have a few cons. One of the cons of the solenoids is that the stroke length of the solenoids is not very long. Because of this, they cannot be used for tasks that need a long distance to be traveled.

Another con of the solenoids is that they consume a lot of power if they need to operate continuously.

However, if the solenoid has a high duty cycle, it may begin to produce heat. Last, the force output decreases as the stroke gets longer. This is something that has to be thought through well when creating a product.

WL0840 Push Pull Linear Solenoid FAQ

1. What is a linear solenoid that pushes and pulls?

A push-pull linear solenoid is a kind of electromagnetic device that converts electricity into linear motion. It consists of a coil through which electricity flows, thus creating a magnet that moves a plunger or armature, thus pushing or pulling

2 What is the function of a Push Pull Solenoid?

A Push Pull Solenoid functions by creating a magnet when electricity flows through it, thus pulling an iron plunger towards it when it is connected to a power source. As a result, a straight stroke is produced, thus moving a connected mechanism. When it is disconnected from a power source, a spring moves the iron plunger back to its original position.

3. What is the difference between solenoids that push and those that pull?

The main difference is in their installation and operation.

Push type solenoid: It pushes a plunger when it is connected to a power source.

Pull type solenoid: It pulls a plunger when it is connected to a power source.

Most solenoids are designed to be push-pull types, meaning they are capable of pushing and pulling a plunger.

4. What things change the strength of a solenoid?

There are several factors that change the power of a solenoid:

Voltage and current input

Temperature

Resistance

Length of wire in a solenoid

Current flow in a wire

Resistance of a wire

Length of wire in a wire

The number of turns of the coil, the thickness of the wire

Length of stroke

Quality of the magnetic material

Design of the plunger

Distance between the air gaps

In general, the shorter the stroke, the greater the force.

5 How long does a Push Pull Solenoid usually last?

The duty cycle, the operating temperature, the conditions of use, etc. will all impact the life of the solenoid. If the solenoid is used properly, high-quality solenoids can be expected to last hundreds of thousands to millions of cycles.

6 What are the different voltage levels that solenoids can work with?

Push Pull Linear Solenoids can be designed to work at different voltages, such as

3V DC

DC 5V

DC 6V

DC 12V

DC 24V

You can design it for different voltages according to the application.

7 How do I pick the correct solenoid for what I need?

When selecting a solenoid, please provide the following information:

Force required

Length of stroke required

Power and voltage

Duty cycle

Where you work

Mount size

Time response required

This information will allow us to recommend the best solenoid for your application.

8 What are the most common uses for Push Pull Linear Solenoids?

Push Pull Solenoids are commonly used for:

Automation tools for factories

Smart locks

Selling machines

Office tools

Car parts

Medical devices

Household appliances

How to Choose a Push Pull Linear Solenoid

Choosing the right push-pull linear solenoid is very important to ensure that it functions properly and lasts long. There are several things that you should always consider before you can choose the right push-pull linear solenoid.

Firstly, you should always consider the amount of force that you need to produce. It should always be very clear what amount of force is required to move the load. It is always important to note that engineers should always consider the amount of resistance that may occur as well.

Secondly, you should always consider the length that you need to move the solenoid to complete the task required. This gives the solenoid a chance to know how far the plunger needs to move to complete the task required. It is very important to note that you should always consider the force curve at the right position because the force always decreases as the stroke increases.

Thirdly, you should always consider the voltage and the power used when the solenoid is working. Some of the most common voltages used by push-pull linear solenoids include 6V DC, 12V DC, and 24V DC.

In addition to that, you should always consider the duty cycle when you are choosing a push-pull linear solenoid. Some solenoids can only be used sometimes while others can always be used. It is always important to note that you should always choose the right duty cycle to ensure that the solenoid does not overheat and lasts long.

It is also necessary to check the location of the installation of the solenoid. It is necessary to check the size of the solenoid and the holes for attaching the solenoid, as well as the direction of the plunger.

Another thing to consider is the weather. Software that is subjected to dust, moisture, vibration, and high temperatures may require special protection.

Last but not least, it is also good to consider the quality standards, test processes, and flexibility to modify of a supplier. A good supplier will provide technical support and tailor-made solutions to meet specific requirements of a particular project.

It is now possible for engineers and buyers to select a push pull linear solenoid that best functions, is highly efficient, and lasts long by carefully examining these factors.
